Impact Sockets Hexagonal 12.7mm - 1-2 Square Drive
Product Details:
X
Product Description
| HEXAGONAL & BIHEXAGONAL | ||||||||
| PROD. NO. | FIG. NO. | A | B | C | D | E | A/F | WT. GMS |
| IM8 | 1 | 36 | 21 | 15 | 13.5 | 25 | 8 | 60 |
| IM9 | 1 | 36 | 21 | 15 | 14.5 | 25 | 9 | 65 |
| IM10 | 1 | 36 | 21 | 15 | 17.0 | 25 | 10 | 65 |
| IM11 | 1 | 36 | 21 | 15 | 18.5 | 25 | 11 | 65 |
| IM12 | 1 | 36 | 21 | 15 | 20.0 | 25 | 12 | 65 |
| IM13 | 1 | 36 | 21 | 15 | 21.5 | 25 | 13 | 75 |
| IM14 | 1 | 36 | 21 | 15 | 22.5 | 25 | 14 | 70 |
| IM15 | 1 | 36 | 21 | 15 | 24.0 | 25 | 15 | 80 |
| IM16 | 2 | 38 | - | - | 25.0 | 25 | 16 | 80 |
| IM17 | 2 | 38 | - | - | 26.5 | 26.5 | 17 | 95 |
| IM18 | 2 | 38 | - | - | 28.0 | 28 | 18 | 105 |
| IM19 | 2 | 38 | - | - | 30.0 | 30 | 19 | 120 |
| IM20 | 3 | 40 | 17 | 23 | 31.0 | 30 | 20 | 125 |
| IM21 | 3 | 40 | 17 | 23 | 32.0 | 30 | 21 | 130 |
| IM22 | 3 | 40 | 17 | 23 | 33.5 | 30 | 22 | 140 |
| IM23 | 3 | 43 | 18 | 25 | 35.0 | 30 | 23 | 165 |
| IM24 | 3 | 43 | 18 | 25 | 36.0 | 30 | 24 | 170 |
| IM26 | 3 | 43 | 18 | 25 | 38.9 | 30 | 26 | 175 |
| IM27 | 3 | 43 | 18 | 25 | 40.0 | 30 | 27 | 180 |
| IM28 | 3 | 46 | 19 | 27 | 42.5 | 30 | 28 | 200 |
| IM29 | 3 | 46 | 19 | 27 | 42.5 | 30 | 29 | 215 |
| IM30 | 3 | 46 | 19 | 27 | 44.0 | 30 | 30 | 220 |
| IM31 | 3 | 46 | 19 | 27 | 44.5 | 30 | 31 | 225 |
| IM32 | 3 | 46 | 19 | 27 | 46.5 | 30 | 32 | 245 |
